LV 159 Series Vertical Machining Center
LV 159 CNC Machine Manufacturer in Pune
If you’re searching for an LV 159 Series Vertical Machining Center, you’re likely looking for a powerful machining solution that delivers precision, stability, and long-term performance for demanding industrial applications.
That’s exactly where the LV 159 CNC Machining Center stands out.
At SanMech Autotech Services LLP, we provide robust LV 159 Vertical Machining Centers in Pune engineered for real production environments — ensuring high accuracy, durability, and efficient machining operations.
Key Features of LV 159 Vertical Machining Center in Pune
High Precision Machining Capability
Precision Linear Guideways
Heavy-Duty Machine Construction
Advanced CNC Control System
Real Benefits You’ll See on the Shop Floor
Let’s focus on real production advantages LV 159 Series Vertical Machining Center— not just features.
This makes the LV 159 Series a dependable choice for demanding machining applications.
Applications of LV 159 CNC Machine in Pune
The LV 159 Vertical Machining Center is widely used in:
If your requirement is heavy-duty performance with precision, the LV 159 Series is an ideal solution.
LV 159 CNC Machining Center – Designed for
–
Built for
Efficiency
The LV 159 CNC Machining Center is built for manufacturers who require high rigidity and performance for larger components and intensive machining tasks.
It’s ideal for:
Compared to standard machines, the LV 159 Series offers enhanced strength, improved stability, and consistent machining output.
Technical Overview (Typical Specifications)
- Spindle Speed: High-performance precision spindle
- Table Size: Suitable for large components
- Axis Travel: Flexible machining range
- CNC Control: User-friendly interface
- Tool Capacity: Multi-tool capability
Why Choose SanMech Autotech Services LLP? ?
We understand real-world industrial challenges and machining requirements.
We recommend the right LV 159 CNC Machining Center based on your production needs.
Ensures smooth operations with minimal downtime.
Our machines are trusted across multiple sectors.
Frequently Asked Questions
It is used for heavy-duty precision machining in automotive, engineering, and industrial manufacturing.
Yes, it is an LV 159 Vertical Machining Center designed for industrial applications.
It offers high rigidity, precision, and stability for large and complex machining tasks.
Yes, it is suitable for both batch and continuous production setups.
| MODEL | LV168 | LV178 | LV208 |
|---|---|---|---|
| TABLE | |||
| Table Size (mm) | 1700 × 850 | 2000 × 850 | 2200 × 850 |
| Travel Ranges (X/Y/Z mm) | 1500 / 900 / 850 | 1700 / 900 / 850 | 2000 / 900 / 850 |
| Max. Table Load (kgs) | 2000 | 2500 | 3000 |
| Spindle Nose to Table Surface (mm) | 100 – 950 | 100 – 950 | 100 – 950 |
| T-Slot (Width × Distance × Number mm) | 18 × 150 × 5 | 18 × 150 × 5 | 18 × 150 × 5 |
| SPINDLE | |||
| Tool Shank & Pull Stud | ISO40 | ISO40 | ISO50 |
| Spindle Inner Diameter (mm) | Ø70 | Ø70 | Ø100 |
| Spindle Center to Column (mm) | 950 | 950 | 950 |
| Spindle Speed (rpm) Belt | 40 – 8000 | 40 – 8000 | 40 – 6000 (8000) |
| Spindle Speed (rpm) Gear | L40 – 2000 / H2001 – 8000 | L40 – 2000 / H2001 – 8000 | L40 – 1500 / H1501 – 6000 |
| Draw Bar Force (kgf) | 950 | 950 | 2000 |
| Main Motor (cont/30 min kW) | 11 / 15 | 11 / 15 | 15 / 18.5 |
| FEED RATE | |||
| Rapid Feed Rate (X/Y/Z m/min) | 24 / 24 / 16 | 24 / 24 / 16 | 24 / 24 / 16 |
| Feed Rate (X/Y/Z mm/min) | 10000 | 10000 | 10000 |
| AXIS SERVO MOTOR | |||
| Mitsubishi (kW) | HF703 (7.0) | HF703 (7.0) | HF703 (7.0) |
| Fanuc (kW) | α22/3000 (4.0) | α22/3000 (4.0) | α30/4000 (7.0) |
| Siemens (kW) | 1FK7105 (8.2) | 1FK7105 (8.2) | 1FK7105 (8.2) |
| Fagor (kW) | FXM 75.20A (7.0) | FXM 75.20A (7.0) | FXM 75.20A (7.0) |
| Heidenhain (kW) | QSY190C (7.2) | QSY190C (7.2) | QSY190C (9.6) |
| AUTO TOOL CHANGER | |||
| Mag Type | Plate / Disk | Plate / Disk | Disk / Chain |
| Cam Type | Geneva / Dual Arm | Geneva / Dual Arm | Dual Arm |
| Tool Selection (Bi-direction) | Absolute / Random | Absolute / Random | Random |
| Tool Storage Capacity (pcs) | 20 / 24 | 20 / 24 | 24 / 32 |
| Max. Tool Diameter (mm) | Ø90 / Ø100 | Ø90 / Ø100 | Ø115 / Ø127 |
| Max. Tool Length / Weight | 250 mm, 8 kgs | 250 mm, 8 kgs | 350 mm, 20 kgs |
| MISCELLANEOUS | |||
| Air Requirement (kg/cm²) | 6 | 6 | 6 |
| Voltage | 220V, 3Ph, 50/60Hz | 220V, 3Ph, 50/60Hz | 220V, 3Ph, 50/60Hz |
| Power Requirement (kVA) | 40 | 40 | 40 |
| Coolant Tank Capacity (L) | 700 | 700 | 700 |
| Machine Weight (kgs) | 14000 | 15000 | 16000 |
| Machine Height (mm) | 3200 | 3200 | 3200 |
| Floor Space (L×W mm) | 4050 × 2900 | 4450 × 2900 | 5000 × 2900 |
Standard Accessory & Function
- Air blast through spindle
- Air blast for workpiece (nose)
- Coolant flushing system
- 3 axes telescopic covers
- Full splash guard
- Centralized automatic lubrication system
- Working lamp
- Operation status light
- Cooling system
- Air gun and water spray-gun
- MPG handwheel
- Heat exchanger
- RS-232 Interface
- Rigid tapping
- Spindle oil cooler
- Adjusting tools and box
- Leveling bolts and pads
Optional Accessory & Function
- MITSUBISHI M80 / M830
- FANUC Oi-MF / 31i-MB
- HEIDENHAIN TNC620 / TNC640
- SIEMENS 828D / 840D
- FAGOR 8055i Plus / 8060FL / 8060
QUALITY THROUGH PRECISION INSPECTIONS
Each Pinnacle machine is subject to dynamic and static accuracy tests.
Pinnacle machine accuracy meets VDI 3441, ISO 10791, JIS B6336 and ASME B5 standards.
ARM TYPE ATC
The 24-tool arm type magazine is activated by electric motor transmitted by U-cam mechanism,
featured with the fastest tool change speed and bi-directional random tool selection. (option)
COOLANT THROUGH SPINDLE
Coolant circulates through spindle offer a direct cooling effect on tools, removing heat that
occurs during machining. Combining with filter tank system. (option)
20 BAR HI-PRESSURE PUMP AND TANK
20μm filter and 600L capacity to assure CTS system offers the highest efficacy. (option)
CHIP CONVEYOR
Chip conveyor device in the front side of machine removes chips efficiently. (option)
